The ANGEL U Series Ultrafiltration Systems are engineered to deliver high-flow, reliable water purification for demanding food service environments. Equipped with advanced UF membranes, the system effectively removes residual chlorine, rust, colloids, impurities, and odor, improving water quality while preserving essential minerals. The high-capacity design supports continuous operation for busy kitchens, while automatic flushing helps maintain membrane performance and extends service life. Quick-change filter cartridges enable fast, hygienic replacement with minimal downtime, and flexible installation options allow easy integration into various layouts. The U Series is ideal for restaurants, fast food outlets, hotels, and other dining establishments, meeting the purification needs of steam cabinets, noodle cookers, stoves, soup pots, direct drinking water faucets, ice makers, and water dispensers.
Improve Water Quality
The 0.01µm UF membrane effectively removes particles, colloids, and a wide range of bacteria and viruses.
High Flow Water
Parallel filter connection design delivers a powerful water supply of up to 13 L/min.
Auto-Flushing
Reduces buildup, helping extend filter lifespan.
DIY Water Distribution
Connect with other water treatment equipment to meet custom water usage needs.
Easy Filter Replacement
Twist-to-lock bayonet-style design for easy filter removal.
High Compatibility
Supports optional accessories like pressure gauges for enhanced functionality.
Model | J3364-UFS500 | J3364-UFS1000 |
Flow Rate | 8.3 L/min (2 gpm) | 13 L/min (3.66 gpm) |
Filter | PP + UF + Carbon Fiber | PP + UF x 2 + Carbon Fiber |
Total Filtered Water Capacity | 30000 L (6600 gallons) | 30000 L (6600 gallons) |
Working Pressure | 0.1-0.4 MPa | 0.1-0.4 MPa |
Operating Temperatures | 4-40℃ | 4-40℃ |
Power Consumption | 24 V, 5 W | 24 V, 5 W |
Dimensions (W x D x H) | 495 x 148 x 644 mm | 615 x 148 x 644 mm |
